Name: N3K-C3064TQ-32T
SKU: N3K-C3064TQ-32T
Availability: InStock

N3K-C3064TQ-32T

Model: N3K-C3064TQ-32T – Cisco Nexus 3000 Series
Details: Nexus 3064-32T, 32 10GBase-T and 4 QSFP+ ports
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

N3K-C3064TQ-32T Overview

Quick Specs Figure 1 shows the appearance of N3K-C3064TQ-32T.

Table 1 shows the Quick Specs.

Physical	● 1RU fixed form factor●Cisco Nexus 3064-32T: 48 x 10 Gigabit Ethernet ports (32 10GBASE-T and 4 QSFP+)◦ 32 RJ-45 ports support 100 Mbps and 1 and 10 Gigabit Ethernet◦ 4 QSFP ports support 4 x 10 Gigabit Ethernet or 40 Gigabit Ethernet each● 2 redundant power supplies● 1fan tray with redundant fans● 1 I/O module with management, console, and USB flash memory ports
Performance	● 1.28-Tbps switching capacity● Forwarding rate of 950 mpps● Line-rate traffic throughput (both Layer 2 and 3) on all ports● Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames)
Hardware tables and scalability	MAC addresses
Number of VLANS	4096
Spanning-tree instances	● Rapid Spanning Tree Protocol (RSTP): 512● Multiple Spanning Tree (MST) Protocol: 64
ACL entries	● 2000 ingress● 1000 egress
Routing table	● 16,000 prefixes and 16,000 host entries● 8000 multicast routes
Number of EtherChannels	64 (with vPC)
Number of ports per EtherChannel	32
Buffers	9 MB shared
Boot flash memory	2 GB
Power	Number of power supplies
Power supply types	● AC (forward and reversed airflow)● DC (forward and reversed airflow)
Typical operating power	● CiscoNexus 3064-T◦ 362W (48p with 3m cables; 4 SR4 at 100% load)
AC PSUs● Input voltage● Frequency● Efficiency	● 100 to 240 VAC● 50 to 60 Hz● 89 to 91% at 220V
DC PSUs● Input voltage● Maximum current● Efficiency	● -40 to -72 VDC● 33A● 85 to 88%
Typical heat dissipation	● Cisco Nexus 3064-T◦ 1235 BTU/hr (48p with 3m cables; 4 SR4 at 100% load)
Maximum heat dissipation	● Cisco Nexus 3064-T: 1553 BTU/hr
Cooling	Forward and reversed airflow schemes:● Forward airflow: Port-side exhaust (air enters through fan-tray and power supplies and exits through ports)● Reversed airflow: Port-side intake (air enters through ports and exits through fan-tray and power supplies)Single fan tray with redundant fansHot swappable (must swap within 1 min)
Sound	Measured sound power (maximum)● Fan speed: 40% duty cycle● Fan speed: 60% duty cycle● Fan speed: 100% duty cycle
Environment	Dimensions (height x width x depth)
Weight	● Cisco Nexus 3064-T and 3064-32T: 20.8 lb (9.5 kg)
Operating temperature	32 to 104°F (0 to 40°C)
Storage temperature	-40 to 158°F (-40 to 70°C)
Operating relative humidity	● 10 to 85% noncondensing● Up to 5 days at maximum (85%) humidity● Recommend ASHRAE data center environment
Storage relative humidity	5 to 95% noncondensing
Altitude	0 to 10,000 ft (0 to 3000m)

Get more information
Do you have any question about the N3K-C3064TQ-32T?
Contact us now via Live Chat or sales@metafinitivetech.com

Warrenty Description

100% Low Price Guarantee: Metafinitivetech.com provides high-quality products at low wholesale prices

100% Quality Assurance: All items are ORIGINAL and GENUINE only. Item conditions are “New Sealed” or “Used / Refurbished”. Used & refurbished items are fully tested with good conditions by Cisco-certified Engineers.

Free CCIE Technical Support: Our FREE Cisco CCIE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.

100% Money Back Guarantee: You can contact our customer service team to exchange or return any product that you bought from us.

Flexible Secure Payment & Shipment: Verified authorization: Mcafee Secure, VeriSign Secured

-5%

Click to enlarge

Original price was: $9,474.00.Current price is: $9,000.30.
