N3K-C3164Q-2PK
Model: N3K-C3164Q-2PK – Cisco Nexus 3000 Series
Details: 2 x Nexus 3164Q bundle
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
N3K-C3164Q-2PK Overview
Quick Specs Figure 1 shows the appearance of N3K-C3164Q-2PK.
Table 1 shows the Quick Specs.
| Physical | •2 RU fixed form-factor switch•64 QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes•2 redundant power supplies•3+1 redundant fans•Management, console, and USB flash-memory ports |
| Performance | •5.12 Tbps switching capacity•Forwarding rate up to 3.8 bpps•Line-rate traffic throughput (both Layer 2 and 3) on all ports•Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) |
| Number of VLANS | MSTP: 4096 |
| Number of spanning-tree instances | MSTP: 64RPVST+: 507 |
| Number of access control list (ACL) entries | 1000 to 4000 egress4000 to 16000 ingress |
| Routing table | Maximum number of longest prefix match (LPM) routes 128,000Maximum number of IP host entries 120,000Maximum number of MAC address entries 96,000 |
| Number of EtherChannels | 256 |
| Number of ports per EtherChannel | 32 |
| Buffer size | 48 MB shared |
| System memory | 16 GB |
| Frequency | 50 to 60 Hz |
| Power supply types | AC |
| Typical operating power | 803 Watts (W) with SR4 optics at 100% load; 2 PSUs |
| Maximum power | 1100 Watts (W) |
| AC PSUs•Input voltage•Frequency•Efficiency | •200 to 240 VAC•50 to 60 Hz•93% at 220V |
| Typical heat dissipation | 2739 BTU/hr (with SR4 optics at 100% load) |
| Maximum heat dissipation | 3753 BTU/hr |
| Cooling | Port-side intake and port-side exhaust optionsPort-side intake: YesPort-side exhaust: Post FCS |
| Dimensions (height x width x depth) | 3.48 x 17.41 x 22.32in. (88.4 x 442 x 566 mm) |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Storage temperature | -40 to 158°F (-40 to70°C) |
| Operating relative humidity | •10 to 85% noncondensing•Up to 5 days at maximum (85%) humidityRecommend ASHRAE data center environment |
| Storage relative humidity | 5% to 95% noncondensing |
| Altitude | 0 to 10,000 ft (0 to 3000m) |
| Maximum number of longest prefix match (LPM) routes | 128,000 |
| Maximum number of IP host entries | 120,000 |
| Maximum number of MAC address entries | 96,000 |
| Number of multicast routes | 16,000, up to 60,000 |
| Number of Interior Gateway Management Protocol (IGMP) snooping groups | 8,000, up to 60,000 |
| Maximum number of VLANs | 4000 |
| Maximum number of Virtual Routing and Forwarding (VRF) instances | 1000 |
| Maximum number of links in a PortChannel | 32 |
| Maximum number of ECMP paths | 64 |
| Maximum number of PortChannels | 256 |
| Number of active Switched Port Analyzer (SPAN) sessions | 4 |
| Maximum number of Rapid per-VLAN Spanning Tree (RPVST) instances | 507 |
| Maximum number of Hot Standby Router Protocol (HSRP) groups | 490 |
| Maximum number of Multiple Spanning Tree (MST) instances | 64 |
| Maximum number of tunnel endpoints (VTEP) and VXLAN physical servers (per VLAN) | 10,000 |
| Regulatory compliance | •Products should comply with CE Markings per directives 2004/108/EC and 2006/95/EC |
| Safety | •UL 60950-1 Second Edition•CAN/CSA-C22.2 No. 60950-1 Second Edition•EN 60950-1 Second Edition•IEC 60950-1 Second Edition•AS/NZS 60950-1•GB4943 |
| EMC: Emissions | •47CFR Part 15 (CFR 47) Class A•AS/NZS CISPR22 Class A•CISPR22 Class A•EN55022 Class A•ICES003 Class A•VCCI Class A•EN61000-3-2•EN61000-3-3•KN22 Class A•CNS13438 Class A |
| EMC: Immunity | •EN55024•CISPR24•EN300386•KN24 |
