N5K-C5596UP-FA
Model: N5K-C5596UP-FA – Cisco Nexus 5000 Series Switch
Details: Nexus 5596UP 2RU Chassis, with 2PS, 4 Fans, 48 Fixed 10GE Ports
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
N5K-C5596UP-FA Overview
Quick Specs Figure 1 shows the appearance of N5K-C5596UP-FA.
Table 1 shows the Quick Specs.
| Performance | ● Layer 2 hardware forwarding at 1920 Gbps or 1428 mpps; Layer 3 performance of up to 160 Gbps or 240 mpps● MAC address table entries: 32,000● Low-latency cut-through design that provides predictable, consistent traffic latency regardless of packet size, traffic pattern, or enabled features on 10 Gigabit Ethernet interfaces● Line-rate traffic throughput on all ports |
| Interfaces | ● 48 fixed ports configurable as 1 and 10 Gigabit Ethernet and FCoE or 8/4/2/1-Gbps native Fibre Channel; additional interfaces through up to three expansion modules● Expansion modules● 16-port 1 and 10 Gigabit Ethernet and FCoE module● 8-port 8/4/2/1-Gbps Fibre Channel plus 8-port 1 and 10 Gigabit Ethernet and FCoE module● Unified port module consisting of 16 ports configurable as 8/4/2/1-Gbps Fibre Channel or 1 and 10 Gigabit Ethernet and FCoE● 4-port QSFP expansion module● 12-port 10G BASE-T module (Cisco Nexus 5596T only)● Layer 3 module (Cisco Nexus 5596UP and 5596T only; one per system)● Layer 3 daughter card (Cisco Nexus 5548P and 5548UP only; one per system)● Extension through the Cisco Nexus 2000 Series |
| Layer 2 Features | ● Layer 2 switch ports and VLAN trunks● IEEE 802.1Q VLAN encapsulation● Support for up to 4096 VLANs● Rapid Per-VLAN Spanning Tree Plus (PVRST+) (IEEE 802.1w compatible)● Multiple Spanning Tree Protocol (MSTP) (IEEE 802.1s): 64 instances● Spanning Tree PortFast● Spanning Tree root guard● Spanning Tree Bridge Assurance● Cisco EtherChannel technology (up to 16 ports per EtherChannel)● Cisco vPC technology● Enhanced vPC enable vPC between Cisco Nexus 5000 and 2000 Series as well as between Cisco Nexus 3000 Series and end host● vPC configuration synchronization● Link Aggregation Control Protocol (LACP): IEEE 802.3ad● Advanced port channel hashing based on Layer 2, 3, and 4 information● Jumbo frames on all ports (up to 9216 bytes)● Pause frames (IEEE 802.3x)● Storm control (unicast, multicast, and broadcast)● Private VLANs● Private VLAN over trunks (isolated and promiscuous)● Private VLANs over vPC and EtherChannels● VLAN Remapping● Cisco FabricPath● EvPC and vPC+ with FabricPath● Cisco Adapter FEX● Cisco Data Center VM FEX● Support for up to 24 fabric extenders on each Cisco Nexus 5500 platform |
| Layer 3 Features | ● Layer 3 interfaces: Routed ports on Cisco Nexus 5500 platform interfaces, switch virtual interface (SVI), port channels, subinterfaces, and port channel subinterfaces for a total of 4096 entries● Support for up to 8000 prefixes and up to 16000 IPv4 and 8000 IPv6 host entries● Support for up to 8000 multicast routes● Support for up to 8000 IGMP groups● Support for 1000 VRF entries● Support for up to 4096 VLANs● 16-way equal-cost multipathing (ECMP)● 1664 ingress and 2048 egress access control list (ACL) entries● Routing protocols: Static, Routing Information Protocol Version2 (RIPv2), Enhanced Interior Gateway Routing Protocol (EIGRP), Open Shortest Path First Version 2 (OSPFv2), and Border Gateway Protocol (BGP)● IPv6 Routing Protocols: Static, Open Shortest Path First Version 3 (OPFv3), Border Gateway Protocol (BGPv6), Enhanced Interior Gateway Routing Protocol (EIGRPv6)● IPv6 VRF Lite● Hot-Standby Router Protocol (HSRP) and Virtual Router Redundancy Protocol (VRRP)● ACL: Routed ACL with Layer 3 and 4 options to match ingress and egress ACL● Multicast: Protocol Independent Multicast Version 2 (PIMv2) sparse mode, Source Specific Multicast (SSM), Multicast Source Discovery Protocol (MSDP), Internet Group Management Protocol Versions 2, and 3 (IGMP v2, and v3), and Multicast VLAN Registration (MVR)● Virtual Route Forwarding (VRF): VRF-lite (IP VPN); VRF-aware unicast; and BGP-, OSPF-, RIP-, and VRF-aware multicast● Unicast Reverse Path Forwarding (uRFP) with ACL; strict and loose modes● Jumbo frame support (up to 9216 bytes)● Support for up to 16 fabric extender on each Nexus 5500 with L3 modules● RFC 896 |
| QoS | ● Layer 2 IEEE 802.1p (CoS)● 8 hardware queues per port● Per-port QoS configuration● CoS trust● Port-based CoS assignment● Modular QoS CLI (MQC) compliance – IPv4 and IPv6● ACL-based QoS classification (Layers 2, 3, and 4)● MQC CoS marking● Per-port virtual output queuing● CoS-based egress queuing● Egress strict-priority queuing● Egress port-based scheduling: Weighted Round-Robin (WRR)● Control Plan Policing (CoPP) – IPv4 and IPv6 |
| Security | ● Ingress ACLs (standard and extended) on Ethernet and virtual Ethernet ports● Standard and extended Layer 2 ACLs: MAC addresses, protocol type, etc.● Standard and extended Layer 3 to 4 ACLs: IPv4 and IPv6, Internet Control Message Protocol (ICMP and ICMPv6), TCP, User Datagram Protocol (UDP), etc.● VLAN-based ACLs (VACLs)● Port-based ACLs (PACLs)● Named ACLs● Optimized ACL distribution● ACLs on virtual terminals (VTYs)● ACL logging on management interface● Dynamic Host Configuration Protocol (DHCP) snooping with Option 82● Dynamic Address Resolution Protocol (ARP) Inspection● IP source guard● DHCP relay● Cisco CTS (Authentication and Policy download from ACS)● Ethernet Port Security● IPv6 RACL● IPv6 PACL● IPv6 VACL |
| High-Availability Features | ● In-Service Software Upgrade (ISSU) for Layer 2● Hot-swappable field-replaceable power supplies, fan modules, and expansion modules● 1:1 power redundancy● N:1 fan module redundancy |
| Management | ● Switch management using 10/100/1000-Mbps management or console ports● CLI-based console to provide detailed out-of-band management● In-band switch management● Locator and beacon LEDs on Cisco Nexus 2000 Series● Port-based locator and beacon LEDs● Configuration synchronization● Module preprovisioning● Configuration rollback● Secure Shell Version 2 (SSHv2)● Telnet● AAA● AAA with RBAC● RADIUS● TACACS+● Syslog (8 servers)● Embedded packet analyzer● SNMPv1, v2, and v3 (IPv4 & IPv6)● Enhanced SNMP MIB support● XML (NETCONF) support● Remote monitoring (RMON)● Advanced Encryption Standard (AES) for management traffic● Unified username and passwords across CLI and SNMP● Microsoft Challenge Handshake Authentication Protocol (MS-CHAP)● Digital certificates for management between switch and RADIUS server● Cisco Discovery Protocol Versions 1 and 2● RBAC● Switched Port Analyzer (SPAN) on physical, port channel, VLAN, and Fibre Channel interfaces● Encapsulated Remote SPAN (ERSPAN)● Ingress and egress packet counters per interface● Network Time Protocol (NTP)● Cisco GOLD● Comprehensive bootup diagnostic tests● Call Home● Smart Call Home● Cisco Fabric Manager● Cisco DCNM● CiscoWorks LAN Management Solution (LMS) |
| Data Center Bridging | ● CEE- and IEEE-compliant PFC (per-priority Pause frame support)● PFC link distance support: 3000m● CEE-compliant DCBX Protocol● CEE- and IEEE-compliant Enhanced Transmission Selection |
| Fibre Channel and FCoE Features (Requires Storage Services License) | ● T11 standards-compliant FCoE (FC-BB-5)● T11 FCoE Initialization Protocol (FIP) (FC-BB-5)● Any 10 Gigabit Ethernet port configurable as FCoE● SAN administration separate from LAN administration● FCP● Fibre Channel forwarding (FCF)● Fibre Channel standard port types: E, F, and NP● Fibre Channel enhanced port types: VE, TE, and VF● F-port trunking● F-port channeling● Direct attachment of FCoE and Fibre Channel targets● Up to 240 buffer credits per native Fibre Channel port● Up to 32 VSANs per switch● Fibre Channel (SAN) port channel● Native Interop Mode 1● Native Interop Mode 2● Native Interop Mode 3● Native Interop Mode 4● VSAN trunking● Fabric Device Management Interface (FDMI)● Fibre Channel ID (FCID) persistence● Distributed device alias services● In-order delivery● Port tracking● Cisco N-Port Virtualization (NPV) technology● N-port identifier virtualization (NPIV)● Fabric services: Name server, registered state change notification (RSCN), login services, and name-server zoning● Per-VSAN fabric services● Cisco Fabric Services● Diffie-Hellman Challenge Handshake Authentication Protocol (DH-CHAP) and Fibre Channel Security Protocol (FC-SP)● Distributed device alias services● Host-to-switch and switch-to-switch FC-SP authentication● Fabric Shortest Path First (FSPF)● Fabric binding for Fibre Channel● Standard zoning● Port security● Domain and port● Enhanced zoning● SAN port channels● Cisco Fabric Analyzer● Fibre Channel traceroute● Fibre Channel ping● Fibre Channel debugging● Cisco Fabric Manager support● Storage Management Initiative Specification (SMI-S)● Boot from SAN over VPC/EVPC |
| Generic MIBs | ● SNMPv2-SMI● CISCO-SMI● SNMPv2-TM● SNMPv2-TC● IANA-ADDRESS-FAMILY-NUMBERS-MIB● IANAifType-MIB● IANAiprouteprotocol-MIB● HCNUM-TC● CISCO-TC● SNMPv2-MIB● SNMP-COMMUNITY-MIB● SNMP-FRAMEWORK-MIB● SNMP-NOTIFICATION-MIB● SNMP-TARGET-MIB● SNMP-USER-BASED-SM-MIB● SNMP-VIEW-BASED-ACM-MIB● CISCO-SNMP-VACM-EXT-MIB |
| Layer 3 MIBs | ● UDP-MIB● TCP-MIB● OSPF-MIB● BGP4-MIB● CISCO-HSRP-MIB |
| Fibre Channel MIBs | ● CISCO-ST-TC● CISCO-FC-FE-MIB● CISCO-FCSP-MIB● CISCO-PORT-TRACK-MIB● CISCO-PSM-MIB● CISCO-FC-SPAN-MIB● CISCO-PORT-CHANNEL-MIB● CISCO-RSCN-MIB● CISCO-NS-MIB● CISCO-FCS-MIB● CISCO-DM-MIB● FIBRE-CHANNEL-FE-MIB● CISCO-FC-ROUTE-MIB● CISCO-FSPF-MIB● CISCO-ZS-MIB● CISCO-ZS-EXT-MIB● CISCO-VSAN-MIB● CISCO-CFS-MIB● CISCO-FCPING-MIB● CISCO-FCTRACEROUTE-MIB● CISCO-FDMI-MIB● CISCO-FC-DEVICE-ALIAS-MIB● CISCO-WWNMGR-MIB● FCMGMT-MIB● CISCO-VEDM-MIB● CISCO-FCOE-MIB |
| Ethernet MIBs | ● CISCO-VLAN-MEMBERSHIP-MIB● CISCO-Virtual-Interface-MIB |
| Configuration MIBs | ● ENTITY-MIB● IF-MIB● CISCO-ENTITY-EXT-MIB● CISCO-ENTITY-FRU-CONTROL-MIB● CISCO-ENTITY-SENSOR-MIB● CISCO-FLASH-MIB● CISCO-SYSTEM-MIB● CISCO-SYSTEM-EXT-MIB● CISCO-IP-IF-MIB● CISCO-IF-EXTENSION-MIB● CISCO-SERVER-INTERFACE-MIB● CISCO-NTP-MIB● CISCO-IMAGE-MIB● CISCO-IMAGE-CHECK-MIB● CISCO-IMAGE-UPGRADE-MIB● CISCO-CONFIG-COPY-MIB● CISCO-ENTITY-VENDORTYPE-OID-MIB● CISCO-BRIDGE-MIB |
| Monitoring MIBs | ● DIFFSERV-DSCP-TC● NOTIFICATION-LOG-MIB● DIFFSERV-MIB● CISCO-CALLHOME-MIB● CISCO-SYSLOG-EXT-MIB● CISCO-PROCESS-MIB● RMON-MIB● CISCO-RMON-CONFIG-MIB● CISCO-HC-ALARM-MIB |
| Security MIBs | ● CISCO-AAA-SERVER-MIB● CISCO-AAA-SERVER-EXT-MIB● CISCO-COMMON-ROLES-MIB● CISCO-COMMON-MGMT-MIB● CISCO-RADIUS-MIB● CISCO-SECURE-SHELL-MIB● TCP/IP MIBs● INET-ADDRESS-MIB● TCP-MIB● CISCO-TCP-MIB● UDP-MIB● IP-MIB● CISCO-IP-PROTOCOL-FILTER-MIB● CISCO-DNS-CLIENT-MIB● CISCO-PORTSECURITY- MIB |
| Miscellaneous MIBs | ● START-MIB● CISCO-LICENSE-MGR-MIB● CISCO-FEATURE-CONTROL-MIB● CISCO-CDP-MIB● CISCO-RF-MIB● CISCO-ETHERNET-FABRIC-EXTENDER-MIB● CISCO-BRIDGE-MIB |
| Industry Standards | ● IEEE 802.1D: Spanning Tree Protocol● IEEE 802.1p: CoS prioritization● IEEE 802.1Q: VLAN tagging● IEEE 802.1Qaz: Enhanced transmission selection● IEEE 802.1Qbb: Per-priority Pause● IEEE 802.1s: Multiple VLAN instances of Spanning Tree Protocol● IEEE 802.1w: Rapid reconfiguration of Spanning Tree Protocol● IEEE 802.3: Ethernet● IEEE 802.3ad: LACP with fast timers● IEEE 802.3ae: 10 Gigabit Ethernet● SFF 8431 SFP+ CX1 support● RMON● IEEE 1588-2008: Precision Time Protocol (Boundary Clock) |
| Fibre Channel Standards | ● FC-PH, Revision 4.3 (ANSI/INCITS 230-1994)● FC-PH, Amendment 1 (ANSI/INCITS 230-1994/AM1 1996)● FC-PH, Amendment 2 (ANSI/INCITS 230-1994/AM2-1999)● FC-PH-2, Revision 7.4 (ANSI/INCITS 297-1997)● FC-PH-3, Revision 9.4 (ANSI/INCITS 303-1998)● FC-PI, Revision 13 (ANSI/INCITS 352-2002)● FC-PI-2, Revision 10 (ANSI/INCITS 404-2006)● FC-PI-4, Revision 7.0● FC-FS, Revision 1.9 (ANSI/INCITS 373-2003)● FC-FS-2, Revision 0.91● FC-LS, Revision 1.2● FC-SW-2, Revision 5.3 (ANSI/INCITS 355-2001)● FC-SW-3, Revision 6.6 (ANSI/INCITS 384-2004)● FC-GS-3, Revision 7.01 (ANSI/INCITS 348-2001)● FC-GS-4, Revision 7.91 (ANSI/INCITS 387-2004)● FC-BB-5, Revision 2.0 for FCoE● FCP, Revision 12 (ANSI/INCITS 269-1996)● FCP-2, Revision 8 (ANSI/INCITS 350-2003)● FCP-3, Revision 4 (ANSI/INCITS 416-2006)● FC-MI, Revision 1.92 (INCITS TR-30-2002, except for FL-ports and Class 2)● FC-MI-2, Revision 2.6 (INCITS TR-39-2005, except for FL-ports and Class 2)● FC-SP, Revision 1.6● FC-DA, Revision 3.1 (INCITS TR-36-2004, except for FL-ports, SB-ports and Class 2)● Class of Service: Class 3, Class F● Fibre Channel standard port types: E and F● Fibre Channel enhanced port types: SD and TE |
| SFP+ Optics | Cisco Nexus 5500 platform supports 10 Gigabit Ethernet SFP+ copper Twinax cables for short distances and SFP+ optics (10GBASE-SR, 10GBASE-LR, 10GBASE-ER, GLC-ZX-SM and Cisco Nexus 2000 Series Fabric Extender Transceiver [FET-10G]) for longer distances. SFP+ has several advantages compared to other 10 Gigabit Ethernet connectivity options:● Small 10 Gigabit Ethernet form factor● Optical interoperability with XENPAK, X2, and XFP interface types● Low power consumption● Hot-swappable device● Cisco Nexus 5500 platform products support 8-Gbps Fibre Channel-compatible SFP+ for native Fibre Channel connectivity options; 8-Gbps Fibre Channel-compatible short-reach and 10-km long-reach SFP transceiver modules operate at 8/4/2 Gbps and are supported in the 8‑Gbps-capable native Fibre Channel ports on expansion modules and unified ports |
| Physical (height x width x depth) | 3.47 x 17.3 x 29.5 in. (8.8 x 43.9 x 74.9 cm) |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Nonoperating (storage) temperature | -40 to 158°F (-40 to 70°C) |
| Humidity | 5 to 95% (noncondensing) |
| Altitude | 0 to 10,000 ft (0 to 3000m) |
| Weight | 47.5 lb (21.55 kg) |
