N9K-PUV-3000W-B
Model: N9K-PUV-3000W-B – Nexus Switches Power Supply
Details: Nexus 9500 3000W Universal High Voltage AC/DC Power Supply, Port Side Intake
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
N9K-PUV-3000W-B Overview
Quick Specs Figure 1 shows the appearance of N9K-PUV-3000W-B.
Table 1 shows the Quick Specs.
| Brand | Cisco |
| Product Name | N9K-PUV-3000W-B |
| Product Type | Power Supply Unit |
| Compatibility | Nexus 9500 Series |
| Power Output | 3000W |
| Input Voltage Type | Universal High Voltage AC/DC |
| Airflow Direction | Port Side Intake |
| Input Voltage Range AC | 200-240V |
| Input Voltage Range DC | -48V to -60V |
| Input Frequency | 50-60 Hz |
| Efficiency | 92% Minimum |
| Hot-Swappable | Yes |
| Redundancy Support | Yes |
| Management | Supported via Cisco Nexus 9500 platform |
| MTBF | 500,000 hours |
| Status Indicators | LED for PSU Status |
| Certifications | RoHS, WEEE |
| Environmental Conditions | Operating: 0 to 40��C, Non-operating: -40 to 70��C |
| Humidity Range | 5% to 95% non-condensing |
| Installation | Plug-in module |
