N9K-X96136YC-R
Model: N9K-X96136YC-R – Cisco Nexus 9000 Switch Modules & Cards
Details: 48-port 10, 36-port 25, 4 100 Gigabit Ethernet QSFP line card /w MACSEC
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
N9K-X96136YC-R Overview
Quick Specs Figure 1 shows the appearance of N9K-X96136YC-R.
Table 1 shows the Quick Specs.
| Brand | Cisco |
| Model Name | N9K-X96136YC-R |
| Port Configuration | 48-port 10 Gigabit Ethernet, 36-port 25 Gigabit Ethernet, 4 100 Gigabit Ethernet QSFP |
| MACSEC | Yes |
| Total Ports | 88 |
| Form Factor | Line Card |
| Layer | Layer 2 and Layer 3 |
| Packet Buffer Size | 32 MB |
| Forwarding Rate | 3.6 Billion packets per second (bpps) |
| Switching Capacity | 7.2 Terabits per second (Tbps) |
| Jumbo Frame Support | Yes (9216 bytes) |
| Security Features | 802.1AE MACsec, Port Security |
| Quality of Service (QoS) | Layer 2-4 Classification, Policing |
| IPv4 and IPv6 Routing | Yes |
| Virtualization | VXLAN, NVGRE |
| Environmental Certification | RoHS-5, NEBS Level 3 |
| Power Consumption | Up to 800W |
| Operating Temperature | 32��F to 104��F (0��C to 40��C) |
| Storage Temperature | -40��F to 158��F (-40��C to 70��C) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Compliance | FCC, CE Mark, UL |
| Warranty | Limited Lifetime Warranty |
