NEDD000EX2S0
Model: Huawei NetEngine Series Routers Module NEDD000EX2S0
Details: 2 Channels 10GE Base LAN/WAN SFP+ Optical Interface Board
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
NEDD000EX2S0 Overview
Quick Specs Figure 1 shows the appearance of NEDD000EX2S0.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | NEDD000EX2S0 |
| Product Type | Optical Interface Board |
| Interface Type | SFP+ |
| Channels | 2 |
| Data Rate | 10GE |
| Compliance | IEEE 802.3ae |
| LAN/WAN Support | Yes |
| Power Consumption | < 10W |
| Operating Temperature | -5°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Dimensions | 23.20mm x 16.25mm x 2.48mm |
| Connector Type | LC |
| MTBF | 200,000 hours |
| Hot Swappable | Yes |
| Status Indicators | LED indicators |
| Protocol | 10 Gigabit Ethernet |
| Maximum Distance | 10 km |
| Wavelength | 1310nm |
| EMC | EN 55032/EN 55024 |
