NEDD0AVD8B00
Model: Huawei NetEngine Series Routers Module NEDD0AVD8B00
Details: 8 Channels VDSL2 Interface Board with Bonding Funtion,Annex B Mode
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
NEDD0AVD8B00 Overview
Quick Specs Figure 1 shows the appearance of NEDD0AVD8B00.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | NEDD0AVD8B00 |
| Interface Type | VDSL2 |
| Number of Channels | 8 |
| Bonding Function | Yes |
| Annex Mode | Annex B |
| Max Downstream Rate | 100 Mbps |
| Max Upstream Rate | 50 Mbps |
| Operating Temperature Range | -40°C to 65°C |
| Storage Temperature Range | -40°C to 70°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Dimensions (HxWxD) | 25 mm x 399 mm x 274 mm |
| Power Consumption | 15W max |
| Ethernet Ports | 1 (for management) |
| Compliance | ITU-T G.993.2, G.994.1, G.997.1 |
| Certification | CE, FCC |
| Mounting | 19″ rack mountable |
| Diagnostics | Loopback testing, Performance monitoring |
| Management Interface | Web-based management, CLI, SNMP |
| Firmware Upgrades | Remotely upgradable |
