NEDD16E17502
Model: Huawei NetEngine Series Routers Module NEDD16E17502
Details: 16 Channels E1 Interface Board(75ohm)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
NEDD16E17502 Overview
Quick Specs Figure 1 shows the appearance of NEDD16E17502.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | NEDD16E17502 |
| Number of Channels | 16 |
| Interface Type | E1 |
| Impedance | 75 ohm |
| Board Type | Interface Board |
| Application | Telecommunications |
| Data Rate | 2.048 Mbps |
| Connector Type | BNC |
| Channel Coding | HDB3 |
| Power Consumption | 10 W |
| Voltage Range | -48V DC |
| Dimensions | 235mm x 165mm |
| Operating Temperature | 0-50°C |
| Storage Temperature | -40-70°C |
| Relative Humidity | 5-95% (non-condensing) |
| Installation | Rack-mounted |
| Compliance | ITU-T G.703 |
| Port Speed | 2.048 Mbps |
| Line Code | HDB3 |
| Loopback Testing | Supported |
