-5%
OMXD30009
Model: Huawei High Speed Transceiver OMXD30009
Details: High Speed Transceiver, QSFP+,1310nm, 41.25Gbps,-7dBm,2.3dBm,-11.5dBm,LC,SMF,10km
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
OMXD30009 Overview
Quick Specs Figure 1 shows the appearance of OMXD30009.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | OMXD30009 |
| Product Type | High Speed Transceiver |
| Form Factor | QSFP+ |
| Wavelength | 1310nm |
| Data Rate | 41.25Gbps |
| Transmit Power (Min) | -7dBm |
| Transmit Power (Max) | 2.3dBm |
| Receiver Sensitivity | -11.5dBm |
| Connector | LC |
| Cable Type | SMF (Single Mode Fiber) |
| Max Distance | 10km |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Power Consumption | < 4.5W |
| MTBF | 1 million hours |
| Compliance | RoHS, CE, FCC, TUV, UL |
| EMC | FCC Part 15 Class B, IEC 61000-4-2 |
| Safety Standards | IEC 60950-1, EN 60950-1, UL 60950-1 |
| Warranty | 3 Years |
