OS6450-24X
Model: OS6450-24X – Alcatel-Lucent Network Edge Switches
Details: OS6450-24X: Gigabit Ethernet chassis in a 1U form factor with 24 10/100/1000 BaseT ports. 2 fixed SFP+ (1G/10G) ports and one expansion slot for optional stacking or uplink modules. 10G uplink speed enable by default. Metro feature set requires license upgrade. The bundle includes an internal AC power supply with a United States power cord. user manuals access card. hardware for mounting in a 19″” rack and RJ-45 to DB-9 adaptor.
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
OS6450-24X Overview
Quick Specs Figure 1 shows the appearance of OS6450-24X.
Table 1 shows the Quick Specs.
| Model Number | OS6450-24X |
| Form Factor | 1U |
| Port Types | 24 10/100/1000 BaseT ports |
| SFP+ Ports | 2 fixed SFP+ (1G/10G) ports |
| Expansion Slot | 1 expansion slot for optional stacking or uplink modules |
| Uplink Speed | 10G enabled by default |
| Metro Feature Set | Requires license upgrade |
| Power Supply | Internal AC power supply |
| Power Cord | United States power cord |
| User Manuals | Access card included |
| Mounting Hardware | Included for mounting in a 19″ rack |
| Adaptor | RJ-45 to DB-9 adaptor included |
| Brand | Alcatel-Lucent |
| Switching Capacity | 176 Gbps |
| Throughput | 130.95 Mpps |
| Management | Web-based GUI, SNMP, and CLI |
| Operating Temperature | 0??C to 45??C |
| RAM | 512 MB |
| Flash Memory | 128 MB |
| MAC Address Table Size | 16,000 entries |
| Dimensions | 29 mm x 440 mm x 254 mm |
