OS6450-U24
Model: OS6450-U24 – Alcatel-Lucent Network Edge Switches
Details: OS6450-U24: Gigabit Ethernet chassis in a 1U form factor with 22 100/1000 Base-X SFP ports. 2 combo ports configurable to be 10/100/1000 BaseT or 100/1000 Base-X. 2 fixed SFP+ (1G/10G*) ports and one expansion slot for optional stacking or uplink modules. 10G* uplink speed and metro feature set requires license upgrade. The bundle includes an internal AC power supply with a United States power cord. user manuals access card. hardware for mounting in a 19″” rack and RJ-45 to DB-9 adaptor.
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
OS6450-U24 Overview
Quick Specs Figure 1 shows the appearance of OS6450-U24.
Table 1 shows the Quick Specs.
| Brand | Alcatel-Lucent |
| Model | OS6450-U24 |
| Form Factor | 1U |
| Port Count | 24 |
| 100/1000 Base-X SFP Ports | 22 |
| Combo Ports (10/100/1000 Base-T or 100/1000 Base-X) | 2 |
| Fixed SFP+ Ports (1G/10G) | 2 |
| Expansion Slot for Optional Modules | 1 |
| License Upgrade Required for 10G Uplink Speed | Yes |
| Metro Feature Set Available | Requires License Upgrade |
| Power Supply | Internal AC |
| Power Cord | United States |
| Mounting Hardware | Included for 19″ Rack |
| User Manual | Access Card Included |
| Adapter | RJ-45 to DB-9 |
| Maximum Switching Capacity | 128 Gbps |
| Forwarding Rate | 95 Mpps |
| Operating Temperature | 0??C to 50??C |
| Power Consumption | 95W |
| Dimensional Size | 44.45 mm x 442 mm x 305 mm |
