OS6855-24D

$0.00

Model: OS6855-24D – Alcatel-Lucent Network Access Switches
Details: OS6855-24 Hardened Gigabit Ethernet L3 fixed configuration chassis in a 1U form factor designed to operate in harsh environments. It has 20 RJ-45 connectors individually configurable to 10/100/1000 BaseT four of which are PoE capable and 4 combo ports. On the combo ports. either copper or fiber can be used on a one for one basis. The bundle comes with OS6855-PSL-D power supply. power shelf. user manual access card and rack mounts.
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

Out of stock

Description

OS6855-24D Overview

Quick Specs Figure 1 shows the appearance of OS6855-24D.

Table 1 shows the Quick Specs.

Brand Alcatel-Lucent
Model OS6855-24D
Chassis Type Hardened Gigabit Ethernet L3 fixed configuration
Form Factor 1U
Operation Environment Harsh environments
Ethernet Ports 20 RJ-45 connectors individually configurable to 10/100/1000 BaseT
PoE Capable Ports 4
Combo Ports
Power Supply Included OS6855-PSL-D
Included Components Power shelf, user manual access card, rack mounts
PoE Standard IEEE 802.3af
Maximum PoE Power 15.4W per port
Switching Capacity 88 Gbps
Forwarding Rate 66 Mpps
Operating Temperature Range -20??C to 60??C
Dimensions 44 mm x 432 mm x 302 mm (1.73 in x 17 in x 11.89 in)
Network Protocols IPv4, IPv6
Mounting Options Rack-mountable
Warranty 1 Year
Management Web-based, SNMP
