OS6900-X72-F
Model: OS6900-X72-F – Alcatel-Lucent Network Access Switches
Details: OS6900-X72: 10Gigabit/40Gigabit Ethernet L3 fixed configuration chassis in a 1U form factor with 48 1/10G SFP+ ports and 6 40G QSFP+ ports. QSFP+ ports operate as single 40GE port or Quad-10GE. Console and Ethernet management ports are RJ45. Front to Rear cooling. The chassis includes a 450W AC power supply. A second power supply slot is supported for redundancy. Redundant power supply shall be ordered separately. The bundle ships with user manuals access card and rack mounts.
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
OS6900-X72-F Overview
Quick Specs Figure 1 shows the appearance of OS6900-X72-F.
Table 1 shows the Quick Specs.
| Brand | Alcatel-Lucent |
| Model Name | OS6900-X72-F |
| Form Factor | 1U |
| Interface | 10Gigabit/40Gigabit Ethernet |
| Layer | L3 |
| Configuration | Fixed |
| SFP+ Ports | 48 1/10G |
| QSFP+ Ports | 6 40G |
| QSFP+ Port Modes | Single 40GE or Quad-10GE |
| Console Ports | RJ45 |
| Ethernet Management Ports | RJ45 |
| Cooling | Front to Rear |
| Power Supply | 450W AC |
| Redundant Power Supply Slot | Yes |
| Redundant Power Supply Ordering | Shall be ordered separately |
| Included Accessories | User manuals access card and rack mounts |
| Dimensions | Standard 1U |
| Port Connector Type | SFP+ and QSFP+ |
