OS9-GNI-U24E
Model: OS9-GNI-U24E – Alcatel-Lucent Network Core Switches
Details: 24-unpopulated 1000BaseX ports. Gigabit Ethernet network interface with MiniGBIC (SFP MSA) connectors supports 24 MiniGBIC transceivers. MiniGBIC transceivers not included – See Transceiver section for additional ordering information. Requires E-series CMMs
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
OS9-GNI-U24E Overview
Quick Specs Figure 1 shows the appearance of OS9-GNI-U24E.
Table 1 shows the Quick Specs.
| Brand | Alcatel-Lucent |
| Model | OS9-GNI-U24E |
| Port Type | 1000BaseX |
| Total Ports | 24 |
| Status | Unpopulated |
| Interface Type | Gigabit Ethernet |
| Connector Type | MiniGBIC (SFP MSA) |
| Transceiver Support | 24 MiniGBIC Transceivers |
| Transceivers Included | No |
| Ordering Information | See Transceiver section |
| Compatibility | E-series CMMs |
| Switch Type | Plug-in Module |
| Form Factor | Rack-mountable |
| Environmental Certification | RoHS |
| Data Rate | 1 Gbps per port |
| Dimensions | 1.75 x 15.5 x 11.4 inches (H x W x D) |
| Power Consumption | 15 Watts |
| Operating Temperature | 0��C to 40��C (32��F to 104��F) |
| Storage Temperature | -20��C to 70��C (-4��F to 158��F) |
| Operating Humidity | 10% to 95% (non-condensing) |
| Supported Standards | IEEE 802.3z |
