OSG010N05
Model: Huawei Optical transceiver OSG010N05
Details: Optical transceiver(eSFP,1310nm,1.25Gb/s,-9dBm~-3dBm,-20dBm,LC,SM,10km)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
OSG010N05 Overview
Quick Specs Figure 1 shows the appearance of OSG010N05.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | OSG010N05 |
| Product Type | Optical Transceiver |
| Form Factor | eSFP |
| Wavelength | 1310nm |
| Data Rate | 1.25Gb/s |
| Min. Transmit Power | -9dBm |
| Max. Transmit Power | -3dBm |
| Receiver Sensitivity | -20dBm |
| Connector Type | LC |
| Fiber Type | Single Mode |
| Max. Distance | 10km |
| Power Supply Voltage | 3.3V |
| Power Consumption | < 1W |
| Temperature Range (Operating) | -40°C to 85°C |
| Humidity (Operating) | 0% to 85% |
| Compliance | RoHS, CE |
| MTBF | >1,000,000 hours |
| Safety | IEC 60825-1 Laser Class 1 |
| EMI | FCC Part 15 Class B |
| Warranty | 3 years |
