OSM010C02
Model: Huawei High Speed Transceiver OSM010C02
Details: High Speed Transceiver,CFP,1271~1331nm CWDM,41.25Gb/s,-4dBm,3.5dBm,-11.5dBm,LC,SM,10km
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
OSM010C02 Overview
Quick Specs Figure 1 shows the appearance of OSM010C02.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Product Name | OSM010C02 |
| Transceiver Type | High Speed Transceiver |
| Form Factor | CFP |
| Wavelength | 1271~1331nm CWDM |
| Data Rate | 41.25Gb/s |
| Minimum Optical Power | -4dBm |
| Maximum Optical Power | 3.5dBm |
| Receiver Sensitivity | -11.5dBm |
| Connector Type | LC |
| Cable Type | SM (Single-Mode) |
| Maximum Distance | 10km |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 0% – 85% |
| Power Supply | 3.3V |
| MTBF | 1,000,000 hours |
| Compliance | RoHS |
| Digital Diagnostics | Yes |
| Warranty | 3 years |
