-5%
OST015N00
Model: Huawei OST015N00 Optical Transceiver
Details: Optical Transceiver,eSFP,622M,Single-mode Module(1310nm,15km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
OST015N00 Overview
Quick Specs Figure 1 shows the appearance of OST015N00.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | OST015N00 |
| Type | Optical Transceiver |
| Interface | eSFP |
| Data Rate | 622M |
| Mode Type | Single-mode |
| Wavelength | 1310nm |
| Maximum Distance | 15km |
| Connector Type | LC |
| Temperature Range | -40°C to +85°C |
| Diagnostics | Digital Diagnostic Monitoring (DDM) |
| Power Supply | 3.3V |
| Max Power Consumption | 1W |
| Compliant Standards | SFF-8472, MSA |
| MTBF | 1,000,000 hours |
| EMC | CE, FCC, RoHS |
| Bit Error Rate | < 1.0E-12 |
| Optical Return Loss | °14 dB |
| Receiver Sensitivity | -28dBm |
| Transmission Output Power | -5dBm to 0dBm |
