PAC-60WB
Model: Huawei Power Module PAC-60WB
Details: 60W AC Power Module(No Fan)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
PAC-60WB Overview
Quick Specs Figure 1 shows the appearance of PAC-60WB.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | PAC-60WB |
| Type | AC Power Module |
| Power Output | 60W |
| Cooling | No Fan |
| Input Voltage Range | 100-240V AC |
| Frequency Range | 50/60Hz |
| Output Voltage | 12V DC |
| Efficiency | 85% |
| Operating Temperature | -5°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Humidity | 5% to 95% (non-condensing) |
| Overload Protection | Yes |
| Overvoltage Protection | Yes |
| Short Circuit Protection | Yes |
| MTBF | 200,000 hours |
| Dimensions (HxWxD) | 78mm x 40mm x 150mm |
| Connector Type | IEC C14 |
| Certification | CE, FCC |
| Application | Telecommunications, Data Centers |
