Sold out
PTX-IPLC-B-32
Model: PTX-IPLC-B-32 – Juniper Router PTX Modules & Cards
Details: 32 channel Integrated photonic linecard
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
PTX-IPLC-B-32 Overview
Quick Specs Figure 1 shows the appearance of PTX-IPLC-B-32.
Table 1 shows the Quick Specs.
| Brand | Juniper |
| Model Name | PTX-IPLC-B-32 |
| Number of Channels | 32 |
| Product Type | Integrated Photonic Linecard |
| Channel Spacing | 50 GHz |
| Transmission Capacity per Channel | Up to 200 Gbps |
| Total Capacity | Up to 6.4 Tbps |
| Modulation Formats | QPSK, 16QAM |
| Wavelength Range | C-Band (1530-1565 nm) |
| Optical Output Power | Up to 17 dBm |
| Sensitivity | -16 dBm |
| FEC | Soft-decision forward error correction (SD-FEC) |
| Power Consumption | 350 Watts |
| Form Factor | Linecard |
| Operating Temperature | 0��C to 40��C |
| Storage Temperature | -40��C to 70��C |
| Humidity Range | 5% to 85% (non-condensing) |
| Interface | QSFP28, CFP2 |
| Protocol Compatibility | OTN, Ethernet |
| Software Support | JunOS |
| Management | CLI, SNMP, NETCONF |
| Security | Link encryption |
| Compliance | RoHS, CE |
