PTX10002-36QDD-BB
Model: Juniper PTX10002-36QDD-BB
Details: PTX10000
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
PTX10002-36QDD-BB Overview
Quick Specs Figure 1 shows the appearance of PTX10002-36QDD-BB.
Table 1 shows the Quick Specs.
| Brand | Juniper |
| Model | PTX10002-36QDD-BB |
| Series | PTX10000 |
| Interface | 36 Ports, 100/400GbE |
| Form Factor | 1U |
| Routing Engine | 2 x RE-S-X6-64G+ |
| Power Supply | Redundant AC |
| Cooling | Front-to-Back Airflow |
| Management | Juniper Junos OS |
| Switching Capacity | 14.4 Tbps |
| Forwarding Capacity | 4.8 Bpps |
| Maximum Power Consumption | 1500 W |
| Operating Temperature | 0??C to 40??C |
| Storage Temperature | -40??C to 70??C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (W x H x D) | 17.42 in x 1.72 in x 24.94 in |
| Max. VLANs | 4096 |
| Max. Routes | 8 M |
| Protocols | OSPF, BGP, MPLS, ISIS |
| Security | IPSec, MACsec |
| Warranty | 1 Year |
