Name: S5720-32X-EI-24S-DC
SKU: S5720-32X-EI-24S-DC
Availability: OutOfStock

S5720-32X-EI-24S-DC

$0.00

Details: S5720-32X-EI-24S-DC (24 Gig SFP,4 Ethernet 10/100/1000 ports,4 10 Gig SFP+,DC -48V,front access)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.

Out of stock

S5720-32X-EI-24S-DC Overview

Quick Specs Figure 1 shows the appearance of S5720-32X-EI-24S-DC.

Table 1 shows the Quick Specs.

Switching Capacity	598 Gbit/s
Forwarding Performance	102 Mpps
DRAM and Flash Memory	SDRAM: 2 GBFlash: 340 MB
MAC Address Table	IEEE 802.1d64K MAC address entriesMAC address learning and agingStatic, dynamic, and blackhole MAC address entriesPacket filtering based on source MAC addresses
Fixed Ports	24 x 100/1,000 Base-X SFP, 4 x 10/100/1,000 Base-T, 4 x 10 Gig SFP+
Extended Slot	NA
DRAM and Flash	SDRAM: 2 GBFlash: 340 MB
VLANs	4K VLANsGuest VLAN and voice VLANGVRPMUX VLANVLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports1:1 and N:1 VLAN mappingVLAN-based transparent transmission of protocol packets
Jumbo Frame	12K
Ring Protection	RRPP ring topology and RRPP multi-instanceSmart Link tree topology and Smart Link multi-instance, providing millisecond-level protection switchoverSmart Ethernet Protection (SEP), G.8032 Ethernet Ring Protection Switching (ERPS)STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s)BPDU protection, root protection, and loop protectionBPDU tunnel
MPLS	MPLS L3VPNMPLS L2VPN (VPWS/VPLS)MPLS-TEMPLS QoS
IP Routing	Static routing, RIPv1/v2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, ECMP, and policy-based routing
IPv6 Features	Neighbor Discovery (ND)Path Maximum Transmission Unit (PMTU)IPv6 Ping, IPv6 Tracert, and IPv6 Telnet6to4 tunnel, ISATAP tunnel, and manually configured tunnelACLs based on source IPv6 addresses, destination IPv6 addresses, Layer 4 ports, or protocol typesMulticast Listener Discovery (MLD) v1/v2 snooping
Multicast Forwarding	IGMP v1/v2/v3 snooping and IGMP fast leaveMulticast forwarding in a VLAN and multicast replication between VLANsMulticast load splitting among trunk member portsControllable multicastLayer 2 multicast controlPort-based multicast traffic statistics collectionIGMPv1/v2/v3, Protocol Independent Multicast Sparse Mode (PIM-SM), and Protocol Independent Multicast Dense Mode (PIM-DM), and Protocol Independent Multicast Source-Specific Multicast (PIM-SSM)Multicast Source Discovery Protocol (MSDP)
QoS/ACL	Inbound and outbound traffic rate limiting on a portPacket redirectionBroadcast storm controlPort-based traffic policing and two-rate and three-color CAREight queues per port, Weighted Round Robin (WRR), Deficit Round Robin (DRR)Strict Priority (SP), WRR + SP, and DRR + SP queue scheduling algorithmsWeighted Random Early Detection (WRED)Re-marking of the 802.1p priority and DSCP value of packetsPacket filtering based on Layer 2 to Layer 4 information, including source MAC addresses, destination MAC addresses, source IP addresses, destination IP addresses, TCP/UCD source/destination ports, protocol types, and VLAN IDsPer queue rate limiting and interface traffic shaping1:1, N:1, N:4 port mirroringVLAN mirroring
Security Features	Hierarchical user management and password protectionDoS attack defense, ARP attack defense, and ICMP attack defenseBinding of the IP address, MAC address, interface number, and VLAN ID of a userPort isolation, port security, and sticky MACMAC Forced Forwarding (MFF)Blackhole MAC address entriesLimit on the number of learned MAC addressesIEEE 802.1x authentication and the limit on the number of users on an interfaceAAA authentication, RADIUS authentication, HWTACACS+ authentication, and NACSSH v2.0Hypertext Transfer Protocol Secure (HTTPS)CPU defenseBlacklist and whitelistMACSec
Access Security	DHCP RelayDHCP ServerDHCP SnoopingDHCP ClientDHCP Security
Port Aggregation	LACPUp to 128 trunk groupsUp to 8 member interfaces in each trunk group
Reliability	Ethernet OAM (IEEE 802.3ah and 802.1ag)ITU-Y.1731BFD for BGP/IS-IS/OSPF/static route
Management and Maintenance	iStackVirtual cable testSNMPv1/v2c/v3RMON/RMON2Web-based network management systemSystem logs and multi-level alarmssFlowLLDP/LLDP-MEDSecure Copy Protocol (SCP), TFTP, FTPStore dual software images and configuration files802.3az Energy Efficient Ethernet (EEE)
Interoperability	VLAN-based Spanning Tree (working with PVST/PVST+/RPVST)Link-type Negotiation Protocol (LNP), similar to the Dynamic Trunking Protocol (DTP)VLAN Central Management Protocol (VCMP), similar to the VLAN Trunk Protocol (VTP)
Surge Protection	Surge protection capability of service ports: 6 kV
Operating Environment	Operating temperature:Zero to 1,800m altitude: 0°C to 45°C1,800m to 5,000m altitude: Operating temperature reduces by 1°C for every altitude increase of 220m.Relative humidity: 5% to 95% (non-condensing)
Input Voltage	DC:Rated voltage range: –48V to –60VMaximum voltage range: –36V to –72V
Dimensions (W x D x H)	442 mm x 220 mm x 43.6 mm
Front Power Input	Yes
Typical Power Consumption	55.5W
