S5731S-H24T4X-A
Model: S5731S-H24T4X-A – Huawei S5731 Series Switches
Details: Huawei SS5731 switch, 24 10/100/1000BASE-T ports, 4 10G SFP+, 1 150W AC Power Supply, Distribution model
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
S5731S-H24T4X-A Overview
Quick Specs Figure 1 shows the appearance of S5731S-H24T4X-A.
Table 1 shows the Quick Specs.
| Item | Description |
| Memory (RAM) | 4 GB |
| Flash | 1 GB in total. To view the available flash memory size, run thedisplay versioncommand. |
| Mean time between failures (MTBF) | 57.73 years |
| Mean time to repair (MTTR) | 2 hours |
| Availability | > 0.99999 |
| Service port surge protection | Common mode: ±6 kV |
| Power supply surge protection | Using AC power modules: ±6 kV in differential mode, ±6 kV in common modeUsing DC power modules: ±2 kV in differential mode, ±4 kV in common mode |
| Dimensions (H x W x D) | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.)Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 43.6 mm x 442.0 mm x 448.0 mm (1.72 in. x 17.4 in. x 17.7 in.) |
| Stack ports | 10GE SFP+ ports on the front panel |
| RTC | Supported |
| RPS | Not supported |
| PoE | Not supported |
| Rated voltage range | AC input: 100 V AC to 240 V AC, 50/60 HzHigh-Voltage DC input: 240 V DCDC input: -48 V DC to -60 V DC |
| Maximum voltage range | AC input: 90 V AC to 290 V AC, 45 Hz to 65 HzHigh-Voltage DC input: 190 V DC to 290 V DCDC input: -38.4 V DC to -72 V DC |
| Maximum power consumption (100% throughput, full speed of fans) | 114 W |
| Typical power consumption (30% of traffic load, tested according to ATIS standard) | 88 W |
| Operating temperature | -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Storage temperature | -40°C to +70°C (-40°F to +158°F) |
| Noise under normal temperature (27°C, sound power) | < 57.5 dB(A) |
| Relative humidity | 5% to 95%, noncondensing |
| Operating altitude | 0-5000 m (0-16404 ft.) |
| Certification | EMC certificationSafety certificationManufacturing certification |
