S8700-06-B01
Model: Huawei S8700-06-B01
Details: S8700
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
S8700-06-B01 Overview
Quick Specs Figure 1 shows the appearance of S8700-06-B01.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | S8700-06-B01 |
| Series | S8700 |
| Type | Modular Access Switch |
| Port Configuration | 6 slots |
| Switching Capacity | 5.4 Tbps |
| Forwarding Performance | 3960 Mpps |
| Dimensions (W x D x H) | 442 mm x 220 mm x 665 mm |
| Power Supply | AC: 110-240V, DC: -48V, -60V |
| Operating Temperature | 0??C to 40??C |
| Storage Temperature | -40??C to 70??C |
| Humidity | 5% to 95% (non-condensing) |
| Fan Modules | Front-to-back airflow |
| MAC Address Table | 64K entries |
| VLANs | 4K VLANs |
| Max Power Consumption | 1200W |
| Protocols | IPv4, IPv6, MPLS, QoS |
| IEEE Standards | 802.3, 802.1Q, 802.3ad |
| Safety Compliance | IEC 60950-1, UL 60950-1 |
| EMC Compliance | EN 55022, EN 55024 |
| Warranty | 3 Years |
| Management | CLI, SNMP, RMON |
