SC-SC-3-Meter-Multimode-Fiber-Optic-Cable
Model: SC-SC-3METER
Details: 10Gb Fiber Optic Cable, SC/SC, Multi-mode – 3 Meter (62.5/125 or 50/125 Type)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
SC-SC-3-Meter-Multimode-Fiber-Optic-Cable Overview
Quick Specs Figure 1 shows the appearance of SC-SC-3-Meter-Multimode-Fiber-Optic-Cable.
Table 1 shows the Quick Specs.
| Brand | Cisco |
| Model | SC-SC-3-Meter-Multimode-Fiber-Optic-Cable |
| Cable Length | 3 Meter |
| Connector Type | SC/SC |
| Fiber Mode | Multi-mode |
| Core/Cladding Diameter | 62.5/125 or 50/125 ??m |
| Data Rate Support | 10Gb |
| Insertion Loss | ?? 0.3 dB |
| Return Loss | ?? 50 dB |
| Operating Temperature | -20??C to 70??C (-4??F to 158??F) |
| Storage Temperature | -40??C to 85??C (-40??F to 185??F) |
| Jacket Material | OFNR (Riser) |
| Compliance | RoHS, REACH |
| Jacket Color | Orange |
| Fiber Count | 2 (Duplex) |
| Maximum Tensile Load | 100 N (Installation), 50 N (Long Term) |
| Minimum Bend Radius | 30 mm (Installation), 15 mm (Long Term) |
| Attenuation at 850 nm | ?? 3.5 dB/km |
| Attenuation at 1300 nm | ?? 1.5 dB/km |
| Application | Data Centers, Enterprise Networks, Fiber to the Desk |
| Packaging | Individual Bag |
Get more information
Do you have any question about the SC-SC-3-Meter-Multimode-Fiber-Optic-Cable?
Contact us now via Live Chat or sales@metafinitivetech.com
