SF352-08MP
Model: SF352-08MP – Cisco 350 Series Managed Switches
Details: 8 10/100 ports with 128W power budget, 2 Gigabit copper/SFP combo
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
SF352-08MP Overview
Quick Specs Figure 1 shows the appearance of SF352-08MP.
Table 1 shows the Quick Specs.
| Device Type | Switch – 8 ports – L3 – managed |
| Enclosure Type | Desktop 1U |
| Subtype | Fast Ethernet |
| Ports | 8 x 10/100 (PoE+) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 128 W |
| Performance | Forwarding performance (64-byte packet size): 4.17 Mpps ¦ Switching capacity: 5.6 Gbps |
| Capacity | Virtual interfaces (VLANs): 4096 ¦ ACL rules: 512 ¦ Priority queues: 8 |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, MLDv2, MLD, CIDR |
| Remote Management Protocol | SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP |
| Encryption Algorithm | MD5, SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | Flow control, BOOTP support, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Broadcast Storm Control, Multicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, DHCP server, Dynamic ARP Inspection (DAI), STP Root Guard, Uni-Directional Link Detection (UDLD), fanless, LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), dual firmware images, Neighbor Discovery Protocol (NDP), Class of Service (CoS), Generic Attribute Registration Protocol (GARP), Generic VLAN Registration Protocol (GVRP), DiffServ Code Point (DSCP) support, 1.5MB packet buffer, IP source guard, SmartPort technology, Internet Control Message Protocol (ICMP), Cisco Discovery Protocol, VLAN Double Tagging (Q-in-Q), VLAN mirroring, DNS client, Secure Core Technology (SCT), Private VLAN Edge (PVE), LLDP-MED, Head-of-line (HOL) blocking, IP/Mac/Port Binding (IPMB), Secure Sensitive Data (SSD), ISATAP tunnel support, RA guard, Guest VLAN, User Datagram Protocol (UDP), Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), loopback detection, Telnet client, Unknown Storm Control, BPDU Guard |
| Compliant Standards | UL 60950, FCC Part 15 A, CSA 22.2, USGv6 |
| RAM | 512 MB |
| Flash Memory | 256 MB |
| Status Indicators | System, PoE, link/activity/speed |
| Interfaces | 8 x 100Base-TX RJ-45 PoE+ ¦ 2 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP ¦ 1 x USB management ¦ 1 x console RJ-45 |
| Power Device | External power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 157.2 Watt |
| Cables Included | 1 x console cable |
| Rack Mounting Kit | Included |
| MTBF | 478,335 hours |
| Localization | Kuwait, Qatar, Saudi Arabia, Hong Kong, Malaysia, Singapore, United Kingdom |
| Width | 11 in |
| Depth | 6.7 in |
| Height | 1.7 in |
| Service & Support | Limited warranty – replacement – lifetime – response time: next business day ¦ Technical support – web support – 1 year ¦ Technical support – phone consulting – 1 year |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 – 90% (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 10 – 90% (non-condensing) |
