SF352-08P
Model: SF352-08P – Cisco 350 Series Managed Switches
Details: 8 10/100 ports with 62W power budget, 2 Gigabit copper/SFP combo
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
SF352-08P Overview
Quick Specs Figure 1 shows the appearance of SF352-08P.
Table 1 shows the Quick Specs.
| Device Type | Switch – 8 ports – L3 – managed |
| Enclosure Type | Desktop 1U |
| Subtype | Fast Ethernet |
| Ports | 8 x 10/100 (PoE+) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 62 W |
| Performance | Forwarding performance (64-byte packet size): 4.17 Mpps ¦ Switching capacity: 5.6 Gbps |
| Capacity | Active VLANs: 4096 |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | Static IPv4 routing, CIDR |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI |
| Encryption Algorithm | SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | Layer 3 switching, layer 2 switching, DHCP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, fanless, 1.5MB packet buffer |
| Compliant Standards | UL 60950, FCC Part 15 A, CSA 22.2 |
| RAM | 512 MB |
| Flash Memory | 256 MB |
| Status Indicators | Link/activity |
| Interfaces | 8 x 100Base-TX RJ-45 PoE+ – 62 W | 2 x 1000Base-T RJ-45/SFP | 1 x console RJ-45 management | 1 x USB management |
| Power Device | External power adapter |
| Power Provided | 2 A |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Cables Included | 1 x power cable | 1 x console cable |
| MTBF | 530,716 hours |
| Localization | North America |
| Width | 11 in |
| Depth | 6.7 in |
| Height | 1.7 in |
| Service & Support | Limited warranty – replacement – lifetime – response time: next business day ¦ Technical support – web support – 1 year ¦ Technical support – phone consulting – 1 year |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 – 90% (non-condensing) |
| Min Storage Temperature | -4 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 10 – 90% (non-condensing) |
