SFP-10G-BXD1
Model: Huawei SFP-10G-BXD1 Optical Transceiver
Details: 10GBase,BIDI Optical Transceiver,SFP+,10G,Single-mode Module(TX1330nm/RX1270nm,10km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
SFP-10G-BXD1 Overview
Quick Specs Figure 1 shows the appearance of SFP-10G-BXD1.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | SFP-10G-BXD1 |
| Type | 10GBase BIDI Optical Transceiver |
| Form Factor | SFP+ |
| Data Rate | 10Gbps |
| Wavelength | TX 1330nm / RX 1270nm |
| Distance | 10km |
| Fiber Mode | Single-mode |
| Connector | LC duplex |
| Transmission Type | Bi-Directional |
| Digital Diagnostic Monitoring | Yes |
| Temperature Range | 0°C to 70°C |
| Power Consumption | <1.5W |
| Compliance | RoHS, MSA |
| Compatible Platforms | Various Huawei Switches and Routers |
| Optical Budget | ° 13dB |
| Receiver Sensitivity | < -14.4dBm |
| Maximum Input Power | -1dBm |
| Packaging | Single boxed unit |
| Warranty | 1 year |
| Manufacturer Part Number | 02310PDP |
