SFP-10G-ER-SM1330-BIDI
Model: Huawei SFP-10G-ER-SM1330-BIDI Optical Transceiver
Details: Optical Transceiver,SFP+,10G,BIDI Single-mode Module(TX 1330nm/RX 1270nm,40km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
SFP-10G-ER-SM1330-BIDI Overview
Quick Specs Figure 1 shows the appearance of SFP-10G-ER-SM1330-BIDI.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Model | SFP-10G-ER-SM1330-BIDI |
| Type | Optical Transceiver |
| Form Factor | SFP+ |
| Data Rate | 10 Gbps |
| Transmission Distance | 40 km |
| Wavelength | TX 1330nm / RX 1270nm |
| Connector Type | LC |
| Cable Type | Single-mode |
| Operating Temperature | 0°C to 70°C |
| Compliance | RoHS |
| Digital Diagnostics | Yes |
| Power Supply | 3.3V |
| Power Consumption | < 1.5W |
| Modulation Format | NRZ |
| Receiver Sensitivity | -15 dBm |
| Maximum Output Power | +3 dBm |
| Protocols | 10GBASE-ER |
| Dimensions | 56.5mm x 8.5mm x 13.4mm |
| Application | Data Centers, Enterprise Wiring Closets, Metro Network |
| Hot Swappable | Yes |
