Summit X430-24P P/N: 16517
Model: Summit X430-24P P/N: 16517 – Extreme Summit X430 series switches
Details: 24 10/100/1000BASE-T PoE+, 4 1000BASE-X unpopulated SFP, 1 AC PSU, ExtremeXOS L2
Edge license
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
Summit X430-24P P/N: 16517 Overview
Quick Specs Figure 1 shows the appearance of Summit X430-24P P/N: 16517.
Table 1 shows the Quick Specs.
| Switch Model | Summit X430-24P P/N: 16517 |
| Bandwidth | 56 Gbps |
| Frame Forwarding Rate | 41.6 Mpps |
| Latency | <5 µs (64 byte) |
| Max Packet Size | 9KB (Jumbo Frame Support) |
| VLANs | 4, 094 |
| Ingress ACLs | 1,024 |
| Forwarding Tables | Layer 2/MAC Addresses: 16k; Layer 2/Multicast Groups: 1k |
| CPU, Memory | Single Core CPU, 500 MHz clock; 256MB DRAM; 256MB Compact Flash; 1.5MB packet buffer on 8 and 24 port switches, 3.0MB packet buffer on 48 port switch |
| Ports | 24 x 10/100/1000Base-T (RJ45); 4 x 100/1000BASE-X (SFP) unpopulated ports; 1 x Serial (console port) and 1 x 10/100BASE-T out-of-band management port |
| Switch Power | 55W |
| 802.3at PoE Power | 370W |
| Total Power | 425W |
