Sold out
SYS-2029U-TR4
Model: SUPER MICR SYS-2029U-TR4
Details: Ultra 2U
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
SYS-2029U-TR4 Overview
Quick Specs Figure 1 shows the appearance of SYS-2029U-TR4.
Table 1 shows the Quick Specs.
| Form Factor | 2U Rackmount |
| Processor | Dual Intel Xeon Scalable processors |
| Chipset | Intel C621 |
| Memory | Up to 3TB ECC 3DS LRDIMM, 24 DIMM slots |
| Expansion Slots | 6 PCIe 3.0 x8, 1 PCIe 3.0 x16 |
| Storage | 12 Hot-swap 3.5″ SAS3/SATA3 Drive Bays |
| Networking | 2x 10GBase-T LAN ports, 1 dedicated IPMI LAN port |
| Power Supply | 1000W Redundant Platinum Level (94%) |
| Management | IPMI 2.0 with KVM and Dedicated LAN |
| USB | 5 USB 3.0 ports (2 front, 2 rear, 1 Type A) |
| Video | Onboard VGA |
| Audio | Realteck ALC887 |
| Front I/O Ports | 2 USB 3.0, 1 VGA, 1 COM |
| Rear I/O Ports | 1 VGA, 1 COM, 2 USB 3.0, 2 10GBase-T LAN |
| RAID Support | RAID 0, 1, 5, 10 |
| Operating Temperature | 10??C to 35??C (50??F to 95??F) |
| Dimensions | 88 x 437 x 648 mm (3.46″ x 17.2″ x 25.5″) |
| Compliance | RoHS, CE, FCC |
| Cooling | 4 Heavy Duty Fans |
| Security | Chassis intrusion detection |
