Sold out
SYS-220TP-HTTR
Model: SUPER MICR SYS-220TP-HTTR
Details: TwinPro
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
SYS-220TP-HTTR Overview
Quick Specs Figure 1 shows the appearance of SYS-220TP-HTTR.
Table 1 shows the Quick Specs.
| Brand | SUPER MICR |
| Model | SYS-220TP-HTTR |
| Form Factor | 2U Rackmount |
| Processor | Dual Intel Xeon Scalable Processors |
| Memory Capacity | Up to 4TB DDR4 |
| Memory Type | 24 DIMM slots, ECC RDIMM, LRDIMM |
| Storage Bays | 8 Hot-swap 2.5″ SAS/SATA/NVMe |
| Storage Controller | SATA3 (6Gbps); Optional hardware RAID |
| Network Interface | 2x 10GBase-T LAN with Intel X550-AT2 |
| Expansion Slots | 7 PCIe 3.0 x8 |
| Power Supply | Platinum Level, 2000W Redundant |
| System Management | IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| USB Ports | 2 USB 3.0 rear, 2 USB 2.0 front, 1 USB 3.0 (Type-A) internal |
| Video Output | 1 VGA port |
| Dimensions | 28.5″ x 17.2″ x 3.44″ (H x W x D) |
| Cooling System | 4 heavy duty fans |
| Operating System | Microsoft Windows Server, VMware ESXi, Linux |
| Security Features | Chassis Intrusion Detection |
| Warranty | 3-year limited warranty |
| Environmental | Energy Star compliant |
