Sold out
TQJ-SA800/2500-3
Model: Huawei TQJ-SA800/2500-3 27010210 Omnidirectional Antenna
Details: Omnidirectional Antenna,824~960/1710~2500MHz,3dBi,Vertical Polarization,360DEG,50W,0r,N(F),Yes
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
TQJ-SA800/2500-3 Overview
Quick Specs Figure 1 shows the appearance of TQJ-SA800/2500-3.
Table 1 shows the Quick Specs.
| Brand | Huawei |
| Product Name | TQJ-SA800/2500-3 |
| Antenna Type | Omnidirectional |
| Frequency Range | 824~960/1710~2500MHz |
| Gain | 3dBi |
| Polarization | Vertical |
| Beamwidth | 360 degrees |
| Maximum Power | 50W |
| Impedance | 50 ohms |
| Connector Type | N(F) |
| Indoor/Outdoor | Yes |
| VSWR | ° 1.5:1 |
| Material | Aluminum Alloy |
| Length | 1000 mm |
| Diameter | 20 mm |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | Up to 95% |
| Mounting Method | Pole Mount |
| Color | Gray |
| RoHS Compliant | Yes |
