-5%
UCSC-PSU-930WDC
Model: UCSC-PSU-930WDC – Nexus Switches Power Supply
Details: 930W -48V DC PS, Port-side Intake
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
UCSC-PSU-930WDC Overview
Quick Specs Figure 1 shows the appearance of UCSC-PSU-930WDC.
Table 1 shows the Quick Specs.
| Brand | Cisco |
| Product Name | UCSC-PSU-930WDC |
| Power Output | 930W |
| Voltage | -48V DC |
| Airflow Direction | Port-side Intake |
| Form Factor | Hot-swappable PSU |
| Compatibility | Cisco UCS C-Series Rack Servers |
| Input Voltage Range | -48V to -60V DC |
| Redundancy | Supported |
| Efficiency | Platinum level |
| Cooling | Integrated Fan |
| Operating Temperature | 0??C to 40??C (32??F to 104??F) |
| Storage Temperature | -40??C to 70??C (-40??F to 158??F) |
| Relative Humidity (Operational) | 10% to 90% non-condensing |
| Relative Humidity (Non-operational) | 5% to 95% non-condensing |
| Mean Time Between Failures (MTBF) | Over 100,000 hours |
| Regulatory Compliance | CE, UL, CSA, FCC, RoHS |
| Dimensions(WxDxH) | 8.0 x 14.0 x 4.0 inches (203.2 x 355.6 x 101.6 mm) |
| Product ID | UCSC-PSU-930WDC |
| Manufacturer’s Warranty | 1 Year Limited Warranty |
