-5%
VC6M1CUAA
Model: Huawei VP9600 Series Universal Transcoding VC6M1CUAA Videoconferencing Services Platform
Details: Huawei VC6M1CUAA VP96 series VP9630-8-AC, which include frame,AC power,fan,one Media Processing Module(hardware resource for 24* 1080p30/12*1080p60 ports), 8*1080p30/4*1080p60 ports and software upgradeable
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
VC6M1CUAA Overview
Quick Specs Figure 1 shows the appearance of VC6M1CUAA.
Table 1 shows the Quick Specs.
| Capacity | Dynamic flexible ports：Up to 12 HD 1080p60 ports in CP= 24 HD 1080p30 ports in CP= 48 HD 720p30 ports in CP= 96 4CIF ports in CPVOIP port：Quantity same as that of 1080p30 ports |
| Video Standards and Protocols | ITU-T H.264, H.264 HP, H.264 SVC, H.263, H.263+, H.263++, H.261 |
| People Video Resolution | Resolution: QCIF, CIF, 4CIF, 720p, 1080p |
| Content Video Resolution | Standard resolution from VGA to 1080p60 |
| Audio Standards and Protocols | AAC-LD, HWA-LD, G.722.1*, G.722.1C*, G.711, G.722, G.728, G.729A, G.729AB, G.719, iLBC |
| Other Supported Standards | H.221, H.225, H.235, H.242, H.243, H.245, H.281, H.283, H.460, TIP, FECC, RFC2833, DTMF, SRTP, TLS, T.140, NTP |
| Network | Standards and protocols: ITU-T H.323, H.320 (VP9660&VP9650 support), IETF SIP |
| Management Tools | Support SSH |
| IP QoS | DiffServ (DSCP), Â IP precedence, ARQ |
| Security | Conference password |
| Approval and Compliance | CE, WEEE, RoHS, REACH, FCC, UL, VCCI-A, GOST, C-TICK |
| Operating Environment | Operating temperature: 0℃ ~ 45℃ |
| Highlights | Embedded web, embedded GK(VP9650&VP9630 support) |
| Dimension | 86.1mm(H) × 442mm(W) × 450mm(D), 2U |
| Weight | < 20Kg |
| Power | AC input: 100～240V 50/60HZ |
| Hot spare | MCU, power, network interface, chipset |
