-5%
VC8MA4PEN
Model: Huawei VC8MA4PEN VP9050 HD Videoconferencing Personal Desktop Endpoint
Details: Huawei VC8MA4PEN VP9050,Videoconferencing Terminal(720P,miniMCU,touch screen,cables-South Africa)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
VC8MA4PEN Overview
Quick Specs Figure 1 shows the appearance of VC8MA4PEN.
Table 1 shows the Quick Specs.
| Embedded MCU | • up to 4 HD 720P video endpoints + 3 voice terminals to join the conference.• The embedded MCU supports CP, voice activation, camera control, and chairman token.• two lever cascading• Mixed H.323 and SIP |
| Video Standard & Protocols | • H.264, H.263, H.263+, H.261• ITU-T H.239• VME (Video Motion Enhancement) |
| People Video Resolution | • 1080p(optional), 720p, 4CIF/4SIF• 1080p 30fps(optional), 720p 50/60fps(optional), 720p 30fps• 512kbps for 720p 30fps• 768kbp for720p 50/60fps• 1Mbps for 1080p 30fps• VideoIntensifier• ViewProcessing |
| Camera | • Embedded High Quality CMOS Camera• Video Capture Resolution: 1080p• Automatic Exposure(AE), Automatic White Balance (AWB)• Manual Picture Parameters Control• Rotatable• Private Protection Switch |
| Display | • 21.5 Inch 16:9 LCD• Resolution: 1080p• Luminance: >200cd/m2• Response Time: <5ms• View Angle: -Horizontal: 70 degree-Vertical: 65 degree• Contrast: 700• Luminance, Contrast Control, Rotatable• Support External Source Input |
| Sound System | • 2xEmbedded Mics, Support External Mics• 2xEmbedded Stereo Loudspeakers |
| Content Video Resolution | • SXGA(1280×1024) , XGA(1024×768)• SVGA(800×600) , VGA(640×480) |
| Audio Standard & Protocols | • AAC-LD Stereo, G.722, G.711, G.728• HWA-LD Stereo : Huawei Audio Broadband Low Delay Stereo• Acoustic Echo Cancellation (AEC)• Acoustic Noise Suppression (ANS) 12 dB• Automatic Gain Control (AGC) ± 6 dB• VoiceClear• AudioEnhancer• Audio-Lip Synchronization |
| Other ITU-Supported Standards | • H.221, H.225, H.230, H.231, H.233, H.234, H.235, H.241, H.242, H.243, H.245, H.281, H.283, H.350, H.460, T.140 |
| Network | • Communication Standards: ITU-T H.323,IETF SIP• Network Standards: TCP/IP, FTP, DHCP, SNMP, Telnet, HTTP , HTTPS, PPPoE, RTP,RTCP• Interface:-1-port IP, 10/100 Base-T, 2xRJ45 connectors-1-port wireless ( WCDMA, CDMA2000 EV-DO), USB connectors• Bandwidth-IP: 64kbps~4Mbps-IP: Total 8Mbps (available: Supports up to 4 HD video endpoints + 3 voice terminals to join the conference) |
| Interface | • Audio Input Interfaces-1×3.5mm line in jack -1×3.5mm mic jack• Audio Output Interfaces-1×3.5mm earphone jack -1×3.5mm line out jack• Video Input Interface-1xDVI / YPbPr / VGAVideo Output Interface-1xDVI / YPbPr / VGA• 1xUSB ports |
| Security | • H.235 signaling and media stream encryption• AES media stream encryption• Conference access password• Conference control password• Administrator password• H.323 ID and number binding• IP address and number binding |
| Electrical | • Working voltage: 100-240V AC• Working frequency: 50-60Hz• Power consumption: 100W |
| Environmental Specification | • Operating Temperature: 0-40˚C• Operating Humidity: 10-80% Non-OperatingTemperature: -40˚-85˚C• Non-Operating Humidity (Non-condensing): 0-95%• Peripheral noise: < 46 dBA SPL• Lowest illuminance: 15 lux• Recommended illuminance: > 300 lux• Physical Characteristics• CodecDimensions(LxWxH):542mmx114mmx490mm• Package Dimensions(LxWxH): 685mmx269mmx685mm• Weight: 8.2 kg |
