-5%
VS-S720-10G-3C
Model: VS-S720-10G-3C Cisco Catalyst 6500 Series Supervisor 720
Details: Catalyst 6500/7600 Supervisor 720 VS-S720-10G-3C Supervisor 720 with 2 ports 10GbE and MSFC3 PFC3C
Condition: New Factory SealedUsed
Warranty: 3 Years Warranty.
Description
VS-S720-10G-3C Overview
Quick Specs Figure 1 shows the appearance of VS-S720-10G-3C.
Table 1 shows the Quick Specs.
| Product Description | Catalyst 6500 Supervisor engine 720-10G-VSS (PFC 3C) |
| Devide Tyde | Control Processor |
| Ports | 2 * 10G X2, 2 * 1G SFP, 1 * 10/100/1000 GE |
| Console ports | RS-232 |
| Centralized switching capacity | 720 Gbps |
| Per-slot switching capacity | 40 Gbps |
| Compatibility | ● Cisco 6500 Catalyst Series● Cisco 7600 Catalyst Series |
| FNF (Flexible NetFlow) entries | 128000 |
| Forn Factor | Plug-in Module |
| Memory | ●WS-SUP720 supports 512MB of DRAM for the route processor and 512 MB for the switch processor●64MB or 512MB (s/w image dependent) Boot Flash for SP switch processor and 64-MB of Boot Flash for the route processor |
| Options | Removable storage: 64MB, 128 MB, 256 MB, 512 MB (Compact Flash) |
| Throughput (in hardware) | ● 450 Mpps for IPv4● 225 Mpps for IPv6● 450Mpps for Layer 2 Bridging |
| Routing entries | ● IPV4: 256,000● IPV6: 128,000 |
| NetFlow Entries | 128,000 |
| Security ACL entries | 32,000 |
| Number of interfaces with unique ACLs | 512 |
| MAC ACLs on IP | No |
| Aggregate Traffic Rate-Limiting Policers | 1,023 |
| NAT | Hardware assisted |
| DRAM | ● MEM-S3-1GB: Catalyst 6500 1GB SP DRAM for Sup720 and Sup720-3B● MEM-MSFC2-512MB: Catalyst 6500 512MB DRAM on the MSFC2 or SUP720 MSFC3 |
