VWIC2-2MFT-T1/E1
Model: VWIC2-2MFT-T1/E1 Router Multiflex Voice/WAN interface Card
Details: 2-Port 2nd Gen Multiflex Trunk Voice/WAN Int. Card – T1/E1
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
VWIC2-2MFT-T1/E1 Overview
Quick Specs Figure 1 shows the appearance of VWIC2-2MFT-T1/E1.
Table 1 shows the Quick Specs.
| Product Type | Voice/WAN Interface Card |
| Model Number | VWIC2-2MFT-T1/E1 |
| Ports | 2 |
| Generation | 2nd |
| Supported Interfaces | T1/E1 |
| Connectivity Technology | Wired |
| Form Factor | Plug-in Card |
| Device Supported | Router |
| Data Transfer Rate | Up to 2.048 Mbps |
| Voice Support | Yes |
| Network Standards | ITU-T G.703, G.704 |
| Jitter Attenuation | Yes |
| Frequency Band | T1: 1.544 Mbps, E1: 2.048 Mbps |
| Connectors | 2 x RJ-48C |
| Protocols | Frame Relay, PPP, HDLC |
| Echo Cancellation | Yes |
| Max Power Consumption | 5.9W |
| Operating Temperature | 0��C to 40��C (32��F to 104��F) |
| Storage Temperature | -20��C to 65��C (-4��F to 149��F) |
| Regulatory Compliance | FCC, CE, UL |
