Sold out
XFP-STM64-SM1550-80km
Model: Huawei XFP-STM64-SM1550-80km 02315143 Optical Transceiver
Details: XFP,10G Single-mode Module(1550nm,80km,LC)
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Out of stock
Description
XFP-STM64-SM1550-80km Overview
Quick Specs Figure 1 shows the appearance of XFP-STM64-SM1550-80km.
Table 1 shows the Quick Specs.
| Specification | Details |
| Brand | Huawei |
| Product Name | XFP-STM64-SM1550-80km |
| Form factor | XFP |
| Transmission rate | 10 Gbit/s |
| Fiber Type | Single-mode |
| Wavelength | 1550nm |
| Target transmission distance | Single-mode fiber: 80 km |
| Connector Type | LC |
| Maximum Tx optical power | 4 dBm |
| Minimum Tx optical power | 0 dBm |
| Minimum extinction ratio | 9 dB |
| Rx sensitivity | -24 dBm |
| Overload power | -7 dBm |
Get more information
Do you have any question about the XFP-STM64-SM1550-80km?
Contact us now via Live Chat or sales@metafinitivetech.com
