Xiaomi Mi AX1800 WiFi 6 Router
Model: Xiaomi Mi AX1800 WiFi 6 Router – Xiaomi WiFi Routers
Details: Xiaomi Router AX1800 Five-Core Wifi6 2.4G 5GHz Full Gigabit Dual-Band Router OFDMA Efficient Transmission Low Latency Stable
Condition: New Factory Sealed
Warranty: 3 Years Warranty.
Description
Xiaomi Mi AX1800 WiFi 6 Router Overview
Quick Specs Figure 1 shows the appearance of Xiaomi Mi AX1800 WiFi 6 Router.
Table 1 shows the Quick Specs.
| External dimensions | 247 x 141 x 180 mm |
| Product colour | White |
| Processor | IPQ6000 quad-core A53 1.2 GHz CPU |
| Network Acceleration Engine | Single-core 1.5 GHz NPU |
| Memory | 256 MB |
| 2.4G Wi-Fi | 2×2 (supports up to IEEE 802.11ax protocol with a theoretical maximum speed of 574 Mbps) |
| 5G Wi-Fi | 2×2 (supports up to IEEE 802.11ax protocol, theoretical maximum speed up to 1201 Mbps) |
| Antennas | 4x external antennas |
| Cooling | Passive cooling |
| Product ports | 1x 10/100/1000M adaptive WAN port (Auto MDI/MDIX)3x 10/100/1000M adaptive LAN ports (Auto MDI/MDIX) |
| LED indicator | 2x (System indicator x1, Internet indicator x1) |
| System reset button | 1x |
| Power supply port | 1x |
| Protocol standards | IEEE 802.11 a/b/g/n/ac/ax,IEEE 802.3/3u/3ab |
| Certification standards | GB/T9254-2008;GB4943.1-2011 |
| Dual band | 2.5 GHz and 5 GHz |
| Modulation | 11B:DSSS:DBPSK(1 Mbps), DQPSK(2 Mbps), CCK(5,5/11 Mbps)11A/g:OFDM:BPSK(6/9 Mbps), QPSK(12/18 Mbps), 16QAM(24/36 Mbps),64QAM(48/54 Mbps)11n:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM.Rate set: MCS0-MCS1511AC:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM.Rate set: MSC0-MCS9 (supports 2 streams)11ax:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM,256QAM,1024QAM.Rate set: MCS0-MCS11 (2 streams supported) |
| Operating system | OpenWRT widely customisable intelligent router operating system MiWiFi ROM |
| WiFi Encryption | WPA-PSK/WPA2-PSK/WPA3-SAE encryption,wireless access control (blacklist and whitelist),SSID hiding, smart unauthorized access prevention |
| Network Security | Access control (blacklist, whitelist), guest network, DoS, SPI firewall,IP and MAC Address binding, IP and MAC filtering |
| Manage applications | Supports Web, Android, iOS |
| Power supply | 1x (12 V/1 A) |
| Operating environment temperature | 0°C–40°C |
| Operating humidity | 10%–90% RH (non-condensing) |
| Storage temperature | -40°C–70°C |
| Storage humidity | 5%–90% RH (non-condensing) |
| Package contents | Main unit x 1Network cable x 1Instruction manual x 1Power supply cable x 1 |
